Meet the specification:

ICAO appendix 14; MH5001-2000;

FAA AC150/5345/3 r; FAA AC120-57 a;

GB/T 14394-93; 100 base-t FX/T (IEEE802.3 u);

1000 base-t FX/T (IEEE802.3 z).

Design features:

1. Comprehensive solution: modular design, integrated distribution system, fault location system and navigational lights related

All sorts of monitoring system;

2. High reliability: software system has strong redundancy function, monitoring computer adopts double machine hot backup, the key equipment such as pass

- cable, control execution unit PLC of redundancy, to ensure that each link and reliable operation;

3. A high real time capability: backbone wire speed highest can amount to gigabit, desktop wire speed can reach MB, on-site wire speed can reach 10 m / 100 m;

4. High stability: the average failure-free operation time is 20000 hours;

5. Functionalization, modular design: the system according to the function monitoring site design, its function monitoring site can be arbitrary number increase

Plus, and do not rely on airport actual geographical position. The software modular design makes this system can be flexible increase and decrease

Various kinds of functions, to meet the different requirements of different scale airport;

6. Strong compatible ability: adopt international process change control standard (OPC), make software and hardware fission design, when hardware flat

Table changes, only need to change the hardware service configuration without changes to the software platform, maximize the

Each manufacturer of different equipment compatibility;

7. The perfect network interconnection function: with WEB technology is the core of the B/S (browser/server) structure small information tube

Richard (MIS) system, to improve the thin client solutions for the network to provide interconnection function, client without extra

Install any software;

8. Perfect visibility and operability: lighting monitoring simulation and distribution simulation baimiao baimiao designs, for operating personnel

Provide a good visual effect. All control, display operation terminal of all Chinese interface make system operation more simple

Then, reliable;

9. The perfect data maintenance and report function: the operation information, the running state of the equipment, equipment alarm information has finished

Good Lord for database support, to operating personnel to provide good data query function and report output functions.

Technical performance:

A. system reliability is not less than 99.98%. The system average failure-free operation time can reach 20000 hours;

B. the wire speed can reach 10 m / 100 MBPS,

Cristiano desktop wire speed not less than 100 MBPS,

D. main communication wire speed not less than 1000 MBPS,

E. Main communication medium with double line redundancy;

F. response time: from the command input up to be accept or reject < 0.5 seconds,

From the effective command input to the equipment movement < 1 seconds

The running state of the equipment movement after return to monitor computer < 1 seconds.

Working environment: environmental temperature: 0 ℃ ~ + 40 ℃; Relative humidity: 10% ~ 85%; Height: 3500 m or less.

Operating environment: operating system: Windows NT/Windows; Communication network: Ethernet

Main communication medium: cable or twisted pair; The local communication medium: super five kind of twisted pair.

Application:

Used for airport navigation lighting system monitoring and control.
